The RVF model includes an impeller with backward-curved blades and galvanized sheet metal housing with a white powder-paint coating. When installed on an exterior wall, all ambient noise is kept outside. These fans are lightweight, compact, and simple to install. The housing is removable for immediate access to the motor and wiring connections.
fantech® Exhaust Fan, Series: RVF, 115 VAC, 1.32 A, 60 Hz, 148 W Input, Sheet Metal, Galvanized, Exterior Wall Mount, 140 deg F, 14-1/4 in Length, 17 in Width, 381 cfm, 6 in Duct, 1, 3044 rev/min Impeller Speed Rating
Amperage Rating1.32 A
CFM Rating381 cfm
Duct Size6 in
FinishGalvanized
Frequency Rating60 Hz
Length14-1/4 in
MaterialSheet Metal
Mounting TypeExterior Wall
Phase1
Power Rating148 W Input
SeriesRVF
Speed Rating3044 rev/min Impeller
Temperature Rating140 deg F
Voltage Rating115 VAC
Width17 in
Galvanized steel housing with powder-coat finish
External rotor motor with totally enclosed design allows fans to operate in high moisture, lint and dust laden air
Permanent split capacitor motors feature automatic reset thermal overload protection and sealed ball bearings for long life and maintenance-free operation
100% speed controllable for highly efficient and economical airflow
Automatic reset thermal overload protection
All motors and impellers are designed as one integral unit, allowing for excellent motor heat dissipation, even at low rpm
Permanently lubricated sealed ball bearings
Excellent heat dissipation to ensure long motor life
